| IPC2128SR3-DPF40 |
IPC2128SR3-DPF60 |
| Camera |
| Sensor |
1/2.5″, 8.0 megapixel, progressive scan, CMOS |
| Lens |
4.0mm@F2.0 |
6.0mm@F2.0 |
| DORI Distance |
Lens (mm) |
Detect(m) |
Observe(m) |
Recognize(m) |
Identify(m) |
| 4.0 |
72 |
28.8 |
14.4 |
7.2 |
| 6.0 |
108 |
43.2 |
21.6 |
10.8 |
| Angle of View(H) |
91.6° |
54.2° |
| Angle of view(V) |
47.2° |
32.5° |
| Angle of view(O) |
112.7° |
66.7° |
| Adjustment Range |
Pan: 0°~360° |
Tilt: 0° ~ 90° |
Rotation: 0° ~ 360° |
| Shutter |
Auto/Manual, 1~1/100000s |
| Minimum Illumination |
Colour: 0.05Lux (F2.0, AGC ON)
0Lux with IR on |
| Day/Night |
IR-cut filter with auto switch (ICR) |
| S/N |
>52dB |
| IR Range |
Up to 30m (98ft) IR range |
| wavelength |
850nm |
| IR On/Off Control |
Auto/Manual |
| Defog |
Digital Defog |
| WDR |
120dB |
| Video |
| Video Compression |
Ultra 265,H.265, H.264, MJPEG |
| H.264 code profile |
Baseline profile, Main Profile, High Profile |
| Frame Rate |
Main Stream:8MP (3840*2160), Max 20fps;
Sub Stream:1080P (1920*1080), Max 30fps;
Third Stream:D1(720*576), Max30fps |
| Video Bit Rate |
128 Kbps~16 Mbps |
| 9:16 Corridor Mode |
Supported |
| OSD |
Up to 8 OSDs |
| Privacy Mask |
Up to 8 areas |
| ROI |
Up to 8 areas |
| Motion Detection |
Up to 4 areas |
| Image |
| White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital noise reduction |
2D/3D DNR |
| Smart IR |
Support |
| Flip |
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
| Dewarping |
Support |
| HLC |
Support |
| BLC |
Support |
| Network |
| Protocols |
IPv4,IGMP,ICMP,ARP,TCP,UDP,DHCP, RTP,RTSP,RTCP,DNS,DDNS,NTP,FTP,UPnP,HTTP,HTTPS,SMTP, SSL,QoS |
| Compatible Integration |
ONVIF(Profile S, Profile T), API |
| Client |
EZStation
EZView
EZLive |
| Web Browser |
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
| Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
| Interface |
| Network |
1 RJ45 10M/100M Base-TX Ethernet |
| Certifications |
| Certifications |
CE: EN 60950-1
UL: UL60950-1
FCC: FCC Part 15 |
| General |
| Power |
DC 12V±25%, PoE (IEEE 802.3af) |
| Power consumption: Max 8W |
| Dimensions (L × W × H) |
191.3×72.6×70.9mm (7.5”×2.9”×2.8”) |
| Net Weight |
0.5kg (1.1lb) |
| Material |
Metal |
| Working Environment |
-30℃ ~ 60℃ (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Strorage Environment |
-30℃ ~ 60℃ (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| surge protection |
2KV |
| Ingress Protection |
IP67 |
