PN-E7005-4P-60

$54.00

Four channel PoE++ splitter. Takes a 1 PoE++ input and splits it into 4 PoE+ ports, up to 25W of power at 100M.

Product Overview

This is an indoor 4-ch Gigabit PoE+ Extender made by Petenet (pronounced ‘pet-net’). This extender eliminates the need for a separate power adapter, as the extender draws power directly from a PoE Injector via Cat5/6 UTP cable. All ports are rated for Gigabit Ethernet speed.

Here are a few features of the extender:

  • Extends the range of PoE and Gigabit Ethernet an additional 100 metres
  • Output power: Up to 25W for 2 devices, 12W for 4 devices
  • No power supply required
  • Gigabit full-rate network throughout the whole extended distance
  • Compact size for installation in a ceiling or junction box



Specification

Item Description
No of channels 1 (PoE IN) into 4 (PoE OUT)
Pass through Data Rates 10/100/1000 Mbps hall/full duplex
Power over Ethernet Input Pin Assignment and Polarity:
Both 1/2, 3/6 and 4/5, 7/8
Power over Ethernet Output Pin Assignment and Polarity:1/2(+), 3/6(-)
Output Power Voltage: Up to 12W for 4 PSE or 25W for 2 PSE
Connectors Shielded RJ-45, EIA 568A and 568B
Network Cables Outdoor type Shield category 5 (or higher)
Mounting Wall or shelf
Environment Indoor
Regulatory Compliance IEEE 802.3af(15.4W) (PoE)
IEEE 802.3at (30W)
IEEE 802.3bt 4 Pairs (60W)
Environment Conditions Operating ambient temperature: -10 to 45°C
Operating humidity: Maximum 90%, Non-condensing
Storage Temperature: -30 to 70°C
Storage Humidity: Maximum 95%, Non-condensing
Dimensions 119x 85x 28mm
